Automatic Double Inverted Wire Hanger Forming Machine with 2.2KW Motor for Efficient Hanger Production

Name: Automatic Double Inverted Wire Hanger Forming Machine with 22KW Motor for Efficient Hanger Production
Brand: DURA
Price: 1 USD

Cheap Automatic Double Inverted Wire Hanger Forming Machine with 2.2KW Motor for Efficient Hanger Production for sale

Place of Origin : Jiangsu, China

Brand Name : DURA

MOQ : 5

Machine type : hanger machine

Weight : 1000 kg

Voltage : 380 V

Power : 2.2 kW

Designed capacity : 10 ~ 15 pcs/min

Hanger size range : 17 ~ 19 inch

Wire diameter : φ4.0 ~ 4.5 mm

Servo motor power : 2 kW

Overall dimensions : 2.4 × 1.0 × 1.6 m (main machine)

Wire payoff dimensions : 1.2 × 1.2 × 1.0 m

Packing dimensions : 1.4 × 1.0 × 1.6 m (main machine)

Wire payoff packing : 1.2 × 1.2 × 1.0 m

Model : QK-5

Operation type : automatic

Core components : Motor

Contact Now

Automatic Double Inverted Aluminum Wire Hanger Forming Machine

Product Overview

High-performance automatic forming machine designed for efficient production of double inverted aluminum wire hangers with motor power of 2.2KW and 380V operation.

Automatic Double Inverted Wire Hanger Forming Machine with 2.2KW Motor for Efficient Hanger Production

Technical Specifications

Parameter	Unit	QK-5
Designed capacity	pcs/min	10 ~ 15
Hanger size range	inch	17 ~ 19"
Wire diameter applicable	mm	φ4.0 ~ 4.5
Motor power	KW	2.2
Servo motor power	KW	2
Weight	KGS	1000
Overall dimensions (L×W×H)	M	2.4 × 1.0 × 1.6 (main machine) 1.2 × 1.2 × 1.0 (wire payoff)

Packing & Delivery Information

Main Machine: Packing dimensions: 1.4 × 1.0 × 1.6M

Wire Payoff: Packing dimensions: 1.2 × 1.2 × 1.0M

Customer Support Services

Pre-Sales Services

Inquiry and consulting support
Sample testing support
Factory viewing and inspection

After-Sales Services

Machine installation training
Machine operation training
Overseas engineering support services
